CONTROLS/INSTRUMENTS/ACCESSORIES
9
7
CD98E043
To adjust the headrest (9), raise it to the desired position.
CD99G060
Turn the knob (7) to obtain good back support from the seat back.
Inertia type safety belt (if fitted) TRIM THIS EDGE
Armrest adjustment
8
PH07433
CS98M577
Raise the armrest, and adjust to the desired angle using the knob (8). Then lower the armrest.
Sit comfortably in the operator’s seat, pull out a sufficient length of belt and fasten it. Allow the reel to take up the slack.
!
WARNING: Always fasten your seat belt before starting the engine. The seat belt can help insure your safety if you fasten it correctly and wear it at all times. The seat belt should never be worn loosely or with slack in the system. Never wear the belt in a twisted condition or pinched between the seat structural members.
85
TRIM THIS EDGE RIGHT PAGE
Alt= to hide template information Alt+ to display template information
Headrest adjustment
Template Name: OM_1_col Template Date: 1994_04_29
Lumbar support adjustment
