CONTROLS/INSTRUMENTS/ACCESSORIES
Operator’s compartment fan (optional)
Press the right of the button to open the articulated boom or to extend the mobile component of the adjustable boom.
Template Name: OM_1_col Template Date: 1994_04_29
Press the left of the button to close the articulated boom or to retract the mobile component of the adjustable boom.
Pilot system cancellation control switch (specific to certain countries)
CP95N001
TRIM THIS EDGE
Located on the rear right-hand side of the operator’s seat, the fan is controlled by a three-position switch (low, off, high) located on the bracket. To use the fan, the electric cable must be inserted into the cigarette lighter socket.
Articulated or adjustable boom control (if fitted)
PH07604B
Alt= to hide template information Alt+ to display template information
This control switch is located on the lefthand control arm and is used when driving on the road. When this control switch is operated, it is impossible to operate the stabilizers, the dozer blade (if fitted) or the attachment, and the indicator lamp on the instrument panel comes on.
PH07521
Located on the top of the right-hand control lever, this push-button is used to control the articulated boom or the adjustable boom (whichever is installed).
80
