ELECTRICAL SYSTEM
BATTERIES Check electrolyte level ............................................................. at least once a year
Access to batteries
Checking the electrolyte level
(788 Series)
PG02236
CD99G053
Open the right-hand side door and remove the shield. See “Replacing a battery”.
(788 Compact Series)
Remove the plugs and check the electrolyte level in each battery cell. The level should be between 10 and 15 mm above the separators.
TRIM THIS EDGE
Add distilled water, if necessary. Make sure the battery terminals are clean and coated with grease and that the cables are tightly connected.
CD96C038
Open the right-hand side door and fasten it in open position with the strut.
331
TRIM THIS EDGE RIGHT PAGE
Template Name: OM_1_col Template Date: 1994_04_29
!
WARNING: Before servicing components of the electrical system, place the battery master switch key in the disconnected position (electricity cut off in system).
Alt= to hide template information Alt+ to display template information
Service specifications
