MAINTENANCE/ADJUSTMENTS
Operate the connecting rod control so as to engage it in the hydraulic breaker, then stop the engine and remove the starter switch key. STEP 5 Install the connecting rod/hydraulic breaker linkage pin and then install the retaining hardware (this can vary depending on the mounting arrangement) on the linkage pins. STEP 6 Open the shut-off valves (for opening or closing the circuit) on the lines, if fitted.
Remove the lifting ring and plug the lifting ring hole. STEP 8 Grease the linkage pins. STEP 9
TRIM THIS EDGE
STEP 7
Alt= to hide template information Alt+ to display template information
STEP 4
Template Name: OM_1_col Template Date: 1994_04_29
For hydraulic breaker operation, see “Option pedal” in the “Controls/Instruments/Accessories” Section.
