MAINTENANCE/ADJUSTMENTS
ENGINE ALTERNATOR BELT AND FAN Service specifications Template Name: OM_1_col Template Date: 1994_04_29
Visual check ................................................................Every 10 hours or every day Check drive system..................................................................... Every 1000 hours Check belt tension ...................................................................... Every 1000 hours
Tools required - One 13 mm wrench for hexagonal head screws - One 15 mm wrench for hexagonal head screws STEP 3
STEP 1
TRIM THIS EDGE
CD99G042
PE06831
Remove the fan guard.
Check that the fan is in proper working order (the hub should turn freely without excessive play).
STEP 2
Alt= to hide template information Alt+ to display template information
STEP 4 Check the condition of the belt. Replace it if it is worn or damaged. Install the belt.
PE06828
Loosen the tension roller and remove the belt. Check that the tension roller and pulley are in proper working order (the pulley should move freely).
