MAINTENANCE/ADJUSTMENTS
STEP 7 Install the lower tray and retaining screws.
PE07506
Install the filter and its frame.
RADIATOR AND OIL COOLER Check for leaks .......................................................... Every 10 hours or every day Clean ............................................................................................. Every 250 hours
Cleaning STEP 1 Open the right-hand side door (for 788 Compact series, install the side door retaining strut) and remove the protective grill.
IMPORTANT: Be sure to wear face protection when using compressed air. IMPORTANT: The use of trichloroethylene is strictly forbidden.
STEP 2
!
WARNING: Never leave tools or other objects inside the air intake compartment.
STEP 3 Install the protective grill (for 788 Compact Series, remove the side door retaining strut), then close the side door.
!
WARNING: Before travelling, make sure the side door is properly fastened.
CD99G053
Clean the radiator and oil cooler: - Dry dust: use compressed air. - Mud: clean with a hose. - Greasy deposits: use perchloroethylene. 285
TRIM THIS EDGE RIGHT PAGE
TRIM THIS EDGE
Service specifications
Template Name: OM_1_col Template Date: 1994_04_29
Lock by turning the knob a quarter turn until it engages.
Alt= to hide template information Alt+ to display template information
STEP 6
STEP 5
