P2AL Version. Use the dozer blade and the stabilizers to raise the machine so that the wheels are no longer in contact with the ground. Lower the attachment until the bucket is resting on the ground. P2A+2A Version. Use the front and rear stabilizers to raise the machine so that the wheels are no longer in contact with the ground. Then lower the attachment until the bucket is resting on the ground. STEP 3 PH07829
PL Version. Use the dozer blade to raise the front of the machine slightly so that the front wheels are no longer in contact with the ground. Use the attachment to raise the rear of the machine slightly so that the rear wheels are no longer in contact with the ground and place blocks under the rear axle. P2A Version. Use the stabilizers to raise the rear of the machine slightly so that the rear wheels are no longer in contact with the ground. Use the attachment to raise the front of the machine slightly, so that the front wheels are no longer in contact with the ground and place blocks under the front axle.
Stop the engine and remove the starter switch key. STEP 4
TRIM THIS EDGE
P Version. Use the attachment to raise the front of the machine slightly, so that the front wheels are no longer in contact with the ground. Then place blocks under the front axle. Swing the upperstructure around. Use the attachment to raise the rear of the machine slightly so that the rear wheels are no longer in contact with the ground and place blocks under the rear axle.
CD97H004
Turn the wheel manually until the filling orifice is in horizontal position on the right and remove the plug. STEP 5 The oil should be level with the edge of the orifice. Add oil through this orifice, if necessary. STEP 6 Install the plug. STEP 7 Repeat Steps 4 through 6 for the other reduction gears.
269
