LUBRICATION/FILTERS/FLUIDS
IMPORTANT: The filter element should only be replaced when the fuel tank is nearly empty, to prevent too much fuel from flowing out.
Precleaner sediment removal
STEP 1
1
2 CD99J008
Template Name: OM_1_col Template Date: 1994_04_29
NOTE: A coin can be used to loosen and tighten the bleed screw.
CD99J008
Clean the area around the precleaner head. Place a receptacle of a suitable capacity under the precleaner and remove the filter element by turning the knurled bushing.
TRIM THIS EDGE
Place a receptacle of a suitable capacity under the precleaner. Loosen the bleed screw (1) and unscrew the drain tap (2) a few turns to allow the dirty fuel to flow out, then close the tap. Retighten the bleed screw.
Alt= to hide template information Alt+ to display template information
Filter element replacement
Fuel pre-filter with sediment bowl
245
