LUBRICATION/FILTERS/FLUIDS
Template Name: OM_1_col Template Date: 1994_04_29
Engine oil change and oil filter replacement
IMPORTANT: The opening (1) must not be used to drain the engine crankcase.
Tools required
STEP 3 (788 Series)
- One extension drain hose (delivered with machine) - One filter strap wrench NOTE: Drain the oil while the engine is still warm. The oil will flow more easily. STEP 1 Park the machine on flat, level ground, stop the engine and remove the starter switch key, and then remove the center access panel. PG03427
STEP 2 (788 Series)
(788 Compact Series)
TRIM THIS EDGE
1
Alt= to hide template information Alt+ to display template information
PH04526
Screw the end of the extension drain hose, located in the tool box, onto the crankcase valve. Place the other end in a suitable receptacle and allow the oil to drain.
PG03425
(788 Compact Series)
NOTE: Have a receptacle of a suitable capacity ready. STEP 4 Remove the extension drain hose and install the protection cap on the crankcase drain valve. Place the extension drain hose in the tool box.
PH04523
Remove the protection cap from the drain valve on the engine crankcase. 234
