JOB SITE AND ROAD OPERATION With articulated boom
STEP 3
Template Name: OM_1_col Template Date: 1994_04_29
Extend the boom cylinders and swing the clamshell around the support by operating the boom articulation cylinders and the dipper cylinders simultaneously. The attachment will be within the approved road travel overall dimensions when the boom cylinders and boom articulation cylinders are completely extended and the clamshell beam is in position in its housing on the support. PDH1089
Using the boom and dipper, bring the shell beam, located towards the operator’s compartment into the housing provided for it on the support. STEP 4
STEP 5 Lock the boom and dipper positions using the boom and dipper locking valves. See “Boom locking valve” and “Dipper locking valve” in the “Controls/Instruments/ Accessories” Section.
TRIM THIS EDGE
STEP 6
Alt= to hide template information Alt+ to display template information
PDH1090
With adjustable boom PDH1091
Swing the clamshell around the support by operating the boom cylinders and dipper cylinders simultaneously. The attachment will be within the approved road travel overall dimensions when the marks on the boom cylinder are aligned and when the clamshell beam is in position in its housing on the support.
For the work position, tilt the support towards the undercarriage until it is stopped by the blade support rods.
178
