OPERATING INSTRUCTIONS
TOWING THE MACHINE Template Name: OM_1_col Template Date: 1994_04_29
!
WARNING: Towing is a delicate operation. There is always a certain amount of risk for the operator. The manufacturer’s guarantee does not apply to accidents or problems which occur while towing.
!
WARNING: Never use the towing eye to tow another vehicle.
!
WARNING: The machine must be towed very slowly, for a short distance and only if absolutely necessary.
!
WARNING: A towing bar must be used for all towing operations.
TRIM THIS EDGE
IMPORTANT: Before towing, you must install the stabilizer (if fitted) and dozer blade (if fitted) lock pins. See “Road travel” in the “Job Site and Road Operation” Section. For all towing operations, the front and rear axle universal joints must be uncoupled. STEP 1
STEP 4
Place blocks under the machine wheels.
Alt= to hide template information Alt+ to display template information
Removal of universal joints Tools required - One 19 mm wrench for hexagonal head screws - One towing bar STEP 2 PH07813
Mark both parts before uncoupling them. NOTE: Marking the parts will facilitate their reassembly. STEP 3 Support the front axle universal joint using a sling attached to the undercarriage.
Remove the four screws from the front axle universal joint. STEP 5 Repeat Steps 2 through 4 for the rear axle universal joint.
146
