OPERATING INSTRUCTIONS STEP 5
PH07911
PH07824
Remove the lifting equipment and install the two plastic plugs.
Installation - One 10 mm wrench for hexagonal head screws - One 22 mm wrench for hexagonal head screws - Suitable lifting equipment STEP 1
PH00305
Remove the four cab mounting screws.
TRIM THIS EDGE
Tools required
Alt= to hide template information Alt+ to display template information
STEP 8
NOTE: To access the screws at the front of the cab, the floor cover must be raised.
Raise the cab carefully until it is completely removed from the machine. STEP 7 Lower the cab to the ground and support it with wooden blocks.
PH07824
Remove the two plastic plugs from the cab roof and install suitable lifting equipment.
143
TRIM THIS EDGE RIGHT PAGE
Template Name: OM_1_col Template Date: 1994_04_29
STEP 6
