CONTROLS/INSTRUMENTS/ACCESSORIES To remove the side panels, remove the retaining screws.
Template Name: OM_1_col Template Date: 1994_04_29
IMPORTANT: Do not operate the machine if the side panels have been removed.
!
WARNING: Before travelling, make sure the access panels are fastened in place.
CD99G028
RIGHT-HAND SIDE DOOR 788 Series
788 Compact Series
TRIM THIS EDGE
Alt= to hide template information Alt+ to display template information
CD98J001
CD96C038
The right-hand door provides access to the walkway, the radiator, the oil cooler and the batteries.
!
The right-hand door provides access to the upperstructure, the oil cooler and the batteries. To hold the door open, remove the strut from its housing and install it in the hole provided. When closing, place the strut back in its housing.
WARNING: Never leave tools or other items inside the air intake compartment.
NOTE: Use the starter switch key to lock the side door.
!
WARNING: Before travelling, make sure the side door is securely latched.
100
