Toyota Model 7HBW23 Service Manual
Section 5. Troubleshooting Control Handle Display and Programming
Table 5-6. Service Parameters Parameter Name Unit
Range
Step
Default
Description
10
PIN-key code
0 to 9999
1
1
Capability to assign up to 10 PIN-key codes (for 10 different operators)
14
Creep speed
–10 to 10
1
–5
Defines how much output the power amplifier gives when you reach the first speed sensor. –10 = low speed when reaching first speed sensor 10 = high speed when reaching first speed sensor
20
Hour meter selection
1 to 5
1
2
1 (A.) = key time 2 (b.) = activity time 3 (c.) = drive 4 (d.) = lift 5 (s.) = time to service
21
Battery size
1 to 20
1
8
Battery size selection
25
Service interval
0 to 2000
50
0
Sets/resets service timer. C29 displays when time is up. To reset timer, access this parameter without changing the value.
39
Access code
1 to 4
1
3
Defines what access level service personnel have to parameters. 1 = key switch/operator parameters open, 2 = key switch/operator parameters closed, 3 = keypad/operator parameters open, 4 = keypad/operator parameters closed (when closed, Service Key is required to access truck parameters).
hours
Parameter Description
Parameter 4
Parameter 1
Auto-Plug Braking in Neutral - Defines the truck’s automatic plug-braking characteristic when throttle is reduced (including to neutral). A lower number gives less aggressive deceleration.
Maximum speed value sent to the power amplifier while in Slow mode except during Turtle Torque (gives torque boost if high load is encountered). Parameter 2 Top Speed - Reduces speed value sent from the ETAC to the power amplifier while in Fast mode (all throttle positions). Parameter 3 Acceleration - Defines the truck’s acceleration characteristic when the truck starts from a stop. A high number gives maximum acceleration, a lower number gives less aggressive acceleration.
00700-CL340-05, Issued: 2 May 2005
Parameter 5 Automatic Time Off Interval (touch pad only)The time until the truck is switched OFF (energy saving feature) when the truck is idle and the brake is applied. Time is counted from when the latest power output is requested. If truck has key switch option, the truck never powers OFF. Range is from 1 minute to 20 minutes (a setting of ‘0’ disables automatic time off).
5-19
