Page 56

Toyota Model 7HBW23 Service Manual

Section 5. Troubleshooting Control Handle Display and Programming

Code E151 - Drive Communication Tx Error Reason

ETAC could not send CAN data to the power amplifier.

Possible Cause/ Corrective Action

Short or open circuit in CAN wiring. Electrical noise in CAN wiring caused by bad connection, outside interference, or low voltage (especially while lifting or driving) possibly caused by over-current or short-circuit. Check CAN wiring. Try driving with a known-good battery or in a different environment. Bad power amplifier; ETAC internal error.

Code E157 - CAN-bus Off Error Reason

ETAC detected problem with the CAN-bus.

Possible Cause/ Corrective Action

Short or open circuit in CAN wiring. Electrical noise in CAN wiring caused by bad connection, outside interference, or low voltage. Check CAN wiring. Try driving with a known-good battery or in a different environment. Bad power amplifier; ETAC internal error.

Code E159 - Over Run Error Reason

ETAC detected problem with the CAN-bus.

Possible Cause/ Corrective Action

Short or open circuit in CAN wiring. Electrical noise in CAN wiring caused by bad connection, outside interference, or low voltage. Check CAN wiring. Try driving with a known-good battery or in a different environment. Bad power amplifier; ETAC internal error.

Code E160 - Error In Reversing Circuit Reason

ETAC detected problem with throttle position sensors, including the sensor used to initiate emergency reversing. See “Code C20 - Thumb Control Warning”.

Possible Cause/ Corrective Action

Check the mechanical portions of the throttle controller. Give special attention to the magnet arm alignment with the ETAC sensors and to the non-metallic parts of the emergency reverser. Bad ETAC.

Code E161 - Lower Valve Error Reason

Power amplifier could not detect presence of lower valve coil.

Possible Cause/ Corrective Action

Lower valve missing. Open or short circuit in lower valve or wiring; master control relay missing or stuck open; main contactor open circuit (especially after it has closed); communication error due to PMT. Allow PMT to reboot before turning truck ON. Bad power amplifier.

Code E200 - Field Open Reason

Power amplifier detected open field.

Possible Cause/ Corrective Action

Open circuit in traction motor field circuit. Check traction motor field wiring and field windings in motor. Harness broken. Bad power amplifier.

00700-CL340-05, Issued: 2 May 2005

5-15
