Toyota Model 7HBW23 Service Manual
Section 4. Planned Maintenance Maintenance Guidelines
Daily Perform the daily checks and report any faults or abnormal conditions to your supervisor. Item
Daily or Eight-Hour Checklist
Battery
Check cleanliness and exterior condition. See “Battery Maintenance” on page 6-5. Check the charge. Check the weight. Check the “free play” of the battery. Make sure the battery does not move more than 0.5 in. (13 mm) in any direction.
Battery Connector
Check the connector. Make sure all powered functions shut down when disconnected. Make sure the battery is properly installed.
General Operation
Check that the horn operates when you press the horn button. (Battery must be connected and the Master Control ON/OFF switch must be ON.) Check the speed and thumb controls. Check the steering operation. Check the lifting and lowering functions. Check the operation of the emergency reverse button. Check the operation of the Master ON/OFF Switch. Note any unusual noise during operation, and report it to your supervisor or maintenance personnel.
Brake/Control Handle Decals
Hydraulic System Wheels/Tires
Verify the drive motor does not run while the brake is applied. Check that the control handle returns to the vertical position when released. Warning/Safety/Operational decals must be in position and legible. Contact your local authorized Toyota Industrial Equipment Dealer if any decal is damaged or missing. Check for oil leaks. Check the condition of the drive wheel and load wheels. Remove any steel chips and foreign material to prevent damage to the wheels. Check for gouging and chunking of the surface. If damaged, report to your supervisor or maintenance personnel.
00700-CL340-05, Issued: 2 May 2005
4-3
