Section 3. Systems Overview
Toyota Model 7HBW23 Service Manual
Truck Model Identification
Truck Model Identification
Figure 3-1. Model 7HBW23 Pallet Truck
1581 001.tif
Vehicle Specifications
The total weight of the load must include the pallet and the container or the device holding the load. Category
3-2
Maximum Load Capacity
4,500 lb. (2,041 kg)
Upright Height
50.8 in. (129.1 cm)
Overall Length (Handle Raised)
up to 81.8 in. (207.8 cm)
Overall Width
28.0 in. (711 mm)
Maximum Lift Height
8.65 in. (219.7 mm)
Regular Speed, Maximum
3.9 mph (6.3 kph)
Stopping Distance
6 ft. (1.83 m)
Battery Compartment Width
7.8 or 9.0 in. (198 or 228 mm)
Battery Voltage
24V
Minimum Battery Weight
200 lb. (91 kg)
Maximum Battery Weight
660 lb. (299 kg)
Truck Weight Without Battery
800 lb. (362 kg)
Wheel: Drive
10 x 5 in. Rubber
Wheel: Load
3.25 x 5 in. Polyurethane (2)
