Boom Angle Limit
How to Use the Working Range Limit Function
Raise or lower the boom to the desired angle, and press the upper or lower boom angle limit restriction key. The corresponding limit restriction indicator lamp will flash and the buzzer will sound continuously, indicating that the limit boom angle has been stored in the memory. When the boom is moved back to an angle within the set limit, the limit restriction indicator lamp stops flashing and stays lit and the buzzer stops. Thereafter, the upper or lower boom angle limit restriction indicator lamp flashes and the buzzer sounds continuously whenever the upper or lower limit previously registered is reached. To cancel the boom angle limit function, press the boom angle limit restriction key again. The corresponding boom angle limit restriction indicator lamp will go off.
[NOTICE] ◆If the selected working range limits allow the crane to approach too close to an obstruction, the crane may be contacted or hit, depending on the operational status and the manner in which the load is handled. When selecting limits, allow sufficient clearance. The working range restricting function makes the boom automatically stop at the previously registered boom angles (upper and lower), lifting height, load radius and swing angle, The function is useful for handling a load in a confined place because it defines the area in which the boom can operate. ◆Turning the power off automatically erases all the previous settings stored in memory. To resume the operation, enter the settings all over again. Upper boom angle restricted Lower boom angle restricted
Upper boom angle limit restriction indicator lamp
Lifting height restricted °
Lower boom angle limit restriction indicator lamp
θu H θL
Load radius restricted
Lower boom angle limit restriction key Upper boom angle limit restriction key
Swing restricted
T23234E
R T23233E
Load Moment Indicator (AML-L)
