When the outrigger mode select key is pressed, the outrigger state indicative symbol, front jack symbol and counterweight state indicative symbol flash in accordance with the status that the AML detects on. After making sure that the display conforms to the actual crane conditions, press the register key. The outrigger state indicative symbol, front jack symbol and counterweight state indicative symbol will change from flashing into being marked up continuously and the moment display, rated lifting capacity display and real load display will return to normal display conditions, meaning that the state has been registered. ◆If an outrigger or the front jack is stowed after registration of outrigger status, the registered status is erased. In this case, register the outrigger status again before starting crane operation. ◆Outrigger state indicative symbol is marked up as shown below:
Selecting Operational Status WARNING Should the operational status be incorrectly registered, the crane might overturn or be damaged, leading to a serious accident. Prior to every operation, check that the registered status corresponds to the actual status of the crane.
Selecting Outrigger and Counterweight Status Before turning on the load moment indicator, make sure that the switches below are in the following positions: • In carrier driver’s cab: Key-actuated switch “chassis-superstructure” ....“1” Rocker switch “PTO” ...........................................“ON” • In crane operator’s cab: Starter switch ......................................................“ON” All of the switches above must satisfy the above conditions to turn on the power supply. ◆The “on-rubber stationary” status is the default status and is automatically selected when the power supply is turned on. (The outrigger state indicative symbols and front jack symbol remain off.) ◆Turning the power off automatically erases all the previous settings stored in memory. To resume the operation, enter the settings all over again. Register the outrigger state using the outrigger mode select key and the register key.
Fully extended （23´ 7 1/2˝）
Mid. extended（15´ 9˝）
Min. extended（6´ 9 7/8˝） T30413E
¡ m
¡ ％
Register key
Outrigger mode select key T24767E
