Carrier Traveling Procedure— Summary 3.
WARNING This summary describes briefly the essential steps for traveling the crane. For detailed information on the individual procedures, refer to the appropriate pages in this section of the manual. Do not travel until you have a complete understanding of all the instructions and information given in this section. The precautions you must observed when traveling are described in the "Safety" section at the beginning of this manual. Carefully read the section before traveling the crane. If you find anything abnormal with the crane during traveling, stop the operation immediately, check and locate the cause, and repair any faulty components. To prevent accidents, do not travel until repairs have been completed.
Set the swing lock lever to the “LOCK” position. Swing lock lever
CK E G LO RELEAS
SWIN K LOC
T24727E
Preparatory Steps ◆For detailed information on the individual procedures, refer to the sections shown in parentheses.
1. Set the crane as described in “At the End of Operation” of “Crane Operation Procedure-Summary” section. (“Crane Operation Procedure-Summary” …………P. 12)
2.
Check that the swing brake switch is turned on. (“Swinging the Boom” ………………………………P. 81)
OFF
AML
ON
Swing brake switch
ON
(ON) (OFF)
H
UEL
FREE
L
F
T24748E
