Air Conditioner (Option) WARNING While the engine and the air conditioner are running, be sure not to touch the rotating objects (fan belt, etc.). Do not disconnect the piping of the air conditioner carelessly. To replenish refrigerant gas, do not use an improper method. Touching the air conditioner’s piping is dangerous since it is filled with high-pressure refrigerant gas. Anyone other than qualified persons must not touch the piping.
Maintenance Table No.
1 2 3 4 5 6
Check interval
Component and required operation
1 day
1 week 3 months 6 months
1 year
2 years
● ● ●
Condenser check and cleaning Refrigerant level check Refrigerant piping connection check Inside air filter check and cleaning Outside air filter replacement V-belt check
● ● ●
Condenser Check and Cleaning ・・・・・・・・・・・・・・・・Once a Year (During the Summer)
Refrigerant Level Check ・・・・・・・・・・・・・・・・Once a Year (During the Summer) Turn ON the air conditioner switch. While magnet clutch of the compressor is ON, check the sight glass to see how the bubbles are coming out. No bubbles are seen when the amount is proper. ◆The cover for the inspection port is located upper part on the right of the vehicle.
CAUTION Stop the engine when washing a condenser. [NOTICE] ◆Do not use a detergent. Wash away dirt and dust attached on the fins of condenser with water.
Cover Proper amount of refrigerant
Refrigerant lack (Bubbles are visible) Sight glass
Air Conditioner (Option)
167
