T040030E
Electrical System Maintenance Table No. Component and Required Operation 1
Check Interval
Fuse/Replace
When fuse blows
Fuse Replacement [NOTICE] ◆Be sure to turn OFF the starter switch to prevent a short circuit when replacing a fuse. ◆Using a fuse with a larger capacity than the rated capacity may cause the wiring or electrical devices to be burned in the event of a short circuit. Always replace a fuse with a fuse of the specified capacity. AML Fuse box
Fuse box
BATTERY
AML
BATTERY F1 F2 F3 F4 F5 F6
POSITION CAPACIY No. COLOR OBJECT A L DOLLY BUZZER 5A 473 B 5A 22 LB POWER SOUCE FOR AML C 15A 250 LW POWER SOUCE FOR CRANE D 10A ー LG RESERVE E 15A 152 LY WORKING LAMP 10A 238 LR AIR CONDITIONER(opt.) F G 10A 472 G FAN(opt.) H 10A ー GB RESERVE I 10A ー GW RESERVE J 15A 151 GR CIGAR LIGHTER K 15A 218 GY POWER WINDOW X 5A ー ー SPARE Y 10A ー ー SPARE Z ー SPARE 15A ー
F7 Adjustment cover
BATTERY CNTL 1,2
BATTERY
CNTL 3,4
BATTERY
CNTL 5,6
BATTERY BATTERY
POSITION CAPACIY No. COLOR OBJECT A L RESERVE 5A ー B 5A 234 LB AIR CONDITIONER(opt.) C 15A 225 LW AIR CONDITIONER(opt.) EXTERNAL WARNING LAMP(opt.) D 10A 470 LG DRUM INDICATOR(opt.) E 15A 2 LY POWER WINDOW 10A 226 LR AIR CONDITIONER(opt.) F G 10A 471 G RADIO(opt.) H 10A 37 GB BUZZER 10A 155 GW HORN, OIL LAMP I 15A 150 GR FRONT WINDSHIELD WIPER J K 15A 158 GY WASHER, ROOF WIND WIPER 5A ー X ー SPARE Y 10A ー ー SPARE Z 15A ー ー SPARE T30466E
Electrical System
165
Electrical System
