Gear Oil [NOTICE] ◆Using different brands of gear oil together can change the properties of the gear oil and have an adverse effect on the machine. When gear oil is added, be sure to use the same brand that is in the machine. If a different brand of oil must be used, remove all the remaining gear oil before adding the new oil. ◆Clean the area around the plugs before removing them to prevent dust and other foreign matter from entering. ◆Clean the plugs and plug holes, and wrap sealing tape around the plugs before installing and tightening the plugs.
Maintenance Table No.
Component and Required Operation
1
Winch speed reducer
2
Swing speed reducer
3
Speed reducer (for hydraulic pump)
Check oil level Replace oil Check oil level Replace oil Check oil level Replace oil
Check Interval Number of 100 hrs 250 hrs 500 hrs 1000 hrs Points/Quantity 1 week 1 month 3 months 6 months 1 year ●
2 points 1.06 gal. (4.0 L x 2)
●
1 point 1.0 gal. (3.8 L)
◎
● ●
1 point 0.66 gal. (2.5 L)
●
◎
◎
● ◎：First replacement only
Gear Oil
