Mounting and Dismounting Counterweights WARNING To prevent accidents, never let anyone enter the area under the lifted load when lifting up the counterweights. Do not step foot under the counterweight when they are lowered onto the frame. Use the snap pins to secure the fixing pins (for counterweights No. 1, No. 2 and No. 3) and the counterweight cylinder fixing pins in position.
Components ◆Mount the counterweight in numerical order shown in the figure below. Counterweight control switch Counterweight cylinder
COUNTERWEIGHT CONTROL
Counterweight cylinder fixing pin Fixing pin (for counterweight No. 1) COUNTERWEIGHT CONTROL
Counterweight No.1 (3,700 lbs.)
Fixing pin (for counterweight No. 2)
Counterweight No.2 (4,000 lbs.)
Fixing pin (for counterweight No. 3)
Counterweight No.3 (8,000 lbs.)
Counterweight No.1 or No.2
Stowing bolt A
Stowage support Front Upper face of the carrier frame
Stowing bolt B
Counterweights No.1 + No.2 or Counterweight No.3 Stowage support
