T039910E
◆Place the rope guide pin on the original position.
Stowing the Single Top WARNING When working at an elevated position, use a platform or scissor lift to prevent falling and ensure safety. Stow the single top securely. Use the attached bolts, cotter pins and rings to ensure that the stowing pin, connecting pins, rope guide pins, and hook mounting pins do not slip out of position.
Rope guide pin
T24614E
1. Stow the auxiliary hook block in its stowing position. 5. If the auxiliary wire rope has been employed, follow
2. Take the rope socket out from the auxiliary hook
the steps below. (1) Reeve it through the rope arrester.
block.
Rope socket
Auxiliary hook block
T23287E
Rope arrester
3. Lower the boom all the way down.
T24506E
(2) Attach the rope socket to the anchor on the jib.
4. Remove the weight for the anti-twoblock device and remove the wire rope from the sheaves of the boom head and single top. ◆If the main winch is to be employed after the single top is stowed, pass the wire rope as shown in the figure below.
Rope socket Fixing pin
Guide
T24473E
[NOTICE] ◆Operate the auxiliary winch carefully. If the wire rope is wound too tight, the anchor will be broken. (3) Wind the auxiliary wire rope, leaving it slightly slack.
Main wire rope T24711E
Single Top (Option)
94
Single Top (Option)
