Crane Operator’s Cab Locking and Unlocking
Opening and Closing the Door
Insert the door key in the lock, and rotate it clockwise to lock the door, or counterclockwise to unlock it. ◆Do not leave the crane with the key inserted in the lock.
WARNING The door, if not completely shut, could open when the vehicle is traveling. Before traveling, be sure to close and lock the door.
Leaving the Door Held Open CAUTION
To keep the door open during crane operation, open the door fully and press the lock lever forward with the door fully open. Before closing the door, press the lock lever to the rear.
Do not attempt to shut the door, holding it at the end. Your fingers may be pinched. When shutting the door, hold the door handle.
Door Lock lever
Lock
Outer handle
Lock
T23065E
T23063E
Inner handle
T24204E
From Outside the Cab Pull the outer handle sideways to slide the door open or shut.
From Inside the Cab Pull the inner handle sideways to slide the door open or closed.
