Outriggers This chapter only provides the additional explanation on outriggers which is not described in the separate Crane Carrier Operation and Maintenance Manual. For detailed explanation of outriggers, see the separate Crane Carrier Operation and Maintenance Manual. During travel, stow the outrigger floats in the designated place. When extending the outriggers, attach each outrigger float to the bottom of each jack cylinder.
Outrigger float
Outrigger float T30424E
◆Make sure to insert the lock pin after attaching the outrigger float.
Lock pin T24730E
WARNING Do not extend or retract an outrigger beam or jack unless it is in full view of the operator or signalman. Make sure all personnel and obstructions are clear from the path of the machinery. Unsuspected movement may occur. Outrigger controls are equipped on both right and left sides of the vehicle. When operating outriggers, use the controls on either right or left side where you can watch the movement of the outriggers to be operated. ◆The front jack must be properly extended before crane operation. Outriggers
