82 INSTRUMENTS AND CONTROLS • Power Divider Lockout Switch – See "Inter-Axle Power Divider Lockout (If Equipped)" in the section of this manual. • Power Take-Off Control Switch — Press the top in to turn the PTO on. Push the bottom in to turn it off. • Push Axle Up/Down Switch — The operator controls the raise and lower functions with the instrument panel-mounted auxiliary axle switch(es), and axle loading is controlled by the air regulators which are located inside the cab between the driver and the rider seats. There is one regulator for each axle. Note: To prevent frame damage, the auxiliary axle(s) will automatically raise when the transmission is shifted into reverse.
C0029216
1. Air Pressure Gauge
2. Air Pressure Regulator
• QUAL COMM Panic Button — If your vehicle is equipped with this option, refer to the QUAL COMM literature provided with the vehicle. • Right-Hand Only Door Lock — Push the top in to lock the right-hand door. • Right-Hand Only Window Lift — Press the top of the switch to raise the right-hand window. Press bottom of switch to lower right-hand window. • Shutdown Override Switch — Pressing this switch shortly after the vehicle sounds the engine shutdown alarm, allows 30 additional seconds of . The process can be repeated several times to safely park the vehicle.
CAUTION Continuously overriding the shutdown system may result in severe engine damage.
