INSTRUMENTS AND CONTROLS 71 • Manually through the GuardDog™ Status screen
C0029145
For more information on GuardDog™, Co-Pilot® display and Basic Display, please refer to the V-MAC® IV Operator’s Guide, TS898. 20. Water in Fuel Indicator (Amber) (If Equipped) – Illuminates when water accumulates in the primary fuel filter sediment bowl. Stop the engine and drain the fuel from the sediment bowl. 21. Engine Over Speed Indicator (Red) – Illuminates when maximum engine RPM is exceeded. 22. Trailer Anti-Lock Brake System (ABS) Indicator (Amber) – Indicates an ABS malfunction. If the light turns on and stays on, a malfunction is indicated. For additional information on operating an ABS-equipped vehicle, refer to “Anti-Lock Brake System (ABS)”, page 157of the Operationsection. Note: When an ABS malfunction is detected, anti-lock braking in the affected wheel(s) will be disabled and normal braking will return; the other wheels will retain anti-lock braking. Operate the vehicle normally and have the ABS system serviced to correct the fault. 23. Cruise Control Indicator (Green) – Indicates that cruise control is engaged. 24. Power Take-Off Operating Indicator (Green) – Indicates PTO . 25. Right Turn Signal Indicator (Green) – Flashes green when turn signal is activated. 26. Inter-Axle Power Divider Lockout Indicator (Amber) – Indicates the Inter-Axle Power Divider Lockout is engaged. 27. Reverse Indicator (Amber) – Indicates that the transmission is in Reverse. 28. Automatic Traction Control (ATC) Indicator (Amber) – Indicates that ATC is operating and will flash when in deep mud and snow mode. 29. Neutral Indicator (Amber) – Indicates that the transmission is in Neutral. 30. Fasten Seat Belt Warning Indicator (If Equipped) (Red)
