REPAIR INSTRUCTIONS 78. Install the range shift cylinder into the rear case. Line up the shift fork with the shift rail as the cylinder is installed. Install the cylinder so that the breather vent is facing down and the air port is facing up.
568
570
Figure 568 — Tightening Clamp Plate Capscrew (T313LR/T318LR Shown)
77. Make sure the synchronizer sliding clutch is in the neutral position. Install the range shift fork into the case and engage the fork onto the sliding clutch. The straight side of the fork (1) faces the front and the angled side of the fork (2) faces the rear.
Figure 570 — Installing Range Shift Cylinder
569
The two-position (compound non-neutralizing) range shift cylinder also requires the installation of a gasket before the cylinder can be installed. This gasket must be installed with the red silicone bead of the gasket facing the transmission case as shown in Figure 571. 571
Figure 569 — Installing Range Shift Fork
Figure 571 — Installing Shift Cylinder Gasket
Page 218
