REPAIR INSTRUCTIONS 67. For the extended output shaft transmissions: T313–T318(21)(L21)(LR21), install a new gasket onto the output housing and then install the housing onto the rear case. Note the location of the lubrication hole. 561
69. On the extended output shaft transmissions: T313–T318(21)(L21)(LR21), install the collapsible-type spacer (the correct length of the spacer was previously determined in “Rear Output Housing Reassembly: T313– T318(21)(L21)(LR21)” on page 142). Also install the outer bearing cone into the output housing over the output shaft. 563
Figure 561 — Installing Output Housing (T313L21/T318L21 Shown)
68. Install and tighten the output housing capscrews to the recommended torque specification. 562
Figure 563 — Installing Spacer and Outer Bearing Cone (T313L21/T318L21 Shown)
70. Seat the outer bearing cone and spacer, using a blunt punch and hammer. Working in a circular motion, tap lightly around the inner race of the bearing cone only. 564
Figure 562 — Tightening Output Housing Capscrews (T313L21/T318L21 Shown)
Figure 564 — Seating the Bearing Cone and Spacer (T313L21/T318L21 Shown)
Page 216
