REPAIR INSTRUCTIONS 50. Install the sliding clutch onto the mainshaft. The external teeth on the sliding clutch face rearward. 549
If the “O” stamping is not visible, locate the gear tooth on the countershaft that aligns with the keyway. Mark the closest tooth that aligns with the keyway. Then mark the remaining gears. 550
Figure 549 — Installing the Sliding Clutch
51. Locate the stamped letter “O” on the rear face of each rear countershaft Lo-split gear. If there is no stamped letter, mark the gear tooth on each countershaft that is directly in line with the keyway of the countershaft. Paint a corresponding timing mark on the Hi-range/Hi-split gear tooth, directly in line with the tooth marked on the Lo-split gear. Paint a corresponding timing mark on the Lo-range gear also.
Figure 550 — Marking Rear Countershaft Gears
