REPAIR INSTRUCTIONS 38. Install the front mainshaft rear bearing mainshaft snap ring.
40. Install the front mainshaft rear bearing cover and capscrews. Tighten the capscrews to the specified torque. 539
To install the snap ring that retains the rear bearing, it may be necessary to raise the mainshaft using a pry bar. 538
Figure 539 — Installing Front Mainshaft Rear Bearing Cover (T313L/T318L Shown)
41. Working at the front of the mainshaft, install the third/fourth sliding clutch. 540
Figure 538 — Installing Snap Ring
39. Install the No. 2 (upper right) countershaft rear bearing cover. Determine shim pack thickness for proper bearing preload adjustment, as described earlier for the No. 3 lower countershaft. Tighten the rear cover capscrews to the specified torque.
Page 208
Figure 540 — Installing Sliding Clutch
