REPAIR INSTRUCTIONS 34. Install the No. 2 (upper left, as viewed from the front) countershaft front bearing cover. While holding the shaft with one hand, insert the front bearing cover ensuring a new O-ring is in place. Carefully wiggle or tap cover in place using a soft hammer. Tighten the cover capscrews to the specified torque.
36. Press the sleeve into the mainshaft rear bearing, being careful to support the bearing on its inner race to prevent damage. 536
Do not attempt to pull any bearing cover in place, using the bearing cover capscrews. Damage to the bearings or bearing cover may result. Make sure all components are properly in place before tightening the capscrews. 35. Install the front mainshaft rear bearing thrust spacer onto the mainshaft, against the last snap ring. Make sure that the oil grooves face forward. 535
Figure 536 — Installing Front Mainshaft Rear Bearing
37. Install the front mainshaft rear bearing. 537
Figure 535 — Installing Bearing Spacer (T313LR/T318LR Shown)
Figure 537 — Installing Front Mainshaft Rear Bearing (T313LR/T318LR Shown)
Page 207
