REPAIR INSTRUCTIONS 1. Install the No. 1 (upper right, when viewed from front) and No. 3 (lower) front countershaft front bearing covers and capscrews. Make sure new O-rings are in place. Tighten the capscrews to the specified torque. 514
4. Temporarily position a shim pack over one of the front countershaft rear bearing cover openings. Mark the overhang of the shim pack at the reverse idler shaft opening of the case. This helps position the reverse idler shaft and prevents bearing cover interference with the shaft. Mark all idler shaft openings.
The bearing cover fits into the flat on the idler shaft to retain the shaft and prevent it from rotating. 516
Figure 514 — No. 1 and No. 3 Front Countershaft Front Bearing Covers Installed
2. With the main case in a vertical position, front end down, install the No. 3 (lower) front countershaft into the main transmission case. 515
Figure 516 — Marking Idler Shaft Opening
Figure 515 — Installing Lower No. 3 Countershaft into Main Case
3. Position the countershaft to center it over the front bearing.
