REPAIR INSTRUCTIONS 4. Position the nose of the seal inserter in the cylinder housing shift rail bore. 445
6. Remove the tool and then push on the seal with your finger to make sure it is seated against the O-ring. Also, push on the “V” fold of the seal to make sure it is seated, and to remove some of the fold. 447
Figure 445 — Positioning Tool in Shift Rail Bore
5. Press the plunger down to fully extend the nose. This positions the seal inside the shift rail bore over the O-ring.
Figure 447 — Seal Properly Installed in Shift Rail Bore
7. Align the relief of the range shift cylinder Teflon® seal installer/sizer (tool No. J 47358) with the “V” fold of the seal, and then gently insert the tool into the bore. DO NOT twist the tool as it is being installed.
446
448
Figure 446 — Installing Teflon® Seal
Figure 448 — Inserting Teflon® Seal Installer/Sizer (Tool No. J 47358)
