REPAIR INSTRUCTIONS 1. Install a new filter O-ring and bronze filter into the filter bore of the housing. Set the filter on top of the O-ring.
3. Install the top cover over the range shift valve body. Install cover screws and tighten the screws to the specified torque. 440
Lightly lubricate the O-ring before installation. Overlubricating the O-ring may cause filter restriction. Make sure to properly seat the O-ring. 438
Figure 440 — Installing Top Cover
4. Set the assembly aside for later installation onto the main case shift cover.
Figure 438 — Installing O-Ring and Filter 1. Sintered Bronze Filter 2. Valve Housing
3. Filter O-Ring
2. Position a new top cover seal (if required) into the groove of the top cover. Lightly lubricate the seal before installation, and make sure all portions of the seal are properly seated in the grooves. 439
Figure 439 — Installing Top Cover Seal 1. Housing Top Cover 2. Top Cover Seal
