REPAIR INSTRUCTIONS 34. For the extended output shaft transmissions: T313–T318(21)(L21)(LR21), install the snap ring inside the Hi-range/Hi-split gear, using suitable snap ring pliers. 391
36. On the extended output shaft transmissions: T313–T318(21)(L21)(LR21), install the external-toothed and internal-toothed thrust washers over the front end of the output shaft. Note that the oil grooves of the external-toothed thrust washer face the front of the shaft toward the internal-toothed thrust washer. 393
Figure 391 — Installing Snap Ring into Gear (T313L21/T318L21 Shown)
35. On the extended output shaft transmissions: T313–T318(21)(L21)(LR21), install the Hi-range/Hi-split gear over the end of the output shaft.
Figure 393 — Installing Thrust Washers (T313L21/T318L21 Shown)
37. For the extended output shaft transmissions: T313–T318(21)(L21)(LR21), install the remaining snap ring onto the front end of the output shaft, using suitable snap ring pliers.
392
394
Figure 392 — Installing Hi-Range/Hi-Split Gear (T313L21/T318L21 Shown)
Figure 394 — Installing Snap Ring onto Front of Shaft (T313L21/T318L21 Shown)
Page 158
