REPAIR INSTRUCTIONS 23. Continue alternately installing the remaining friction and steel reaction discs until four of each have been installed. Make sure to lubricate each friction and reaction disc with the specified gear oil during installation. The last disc installed should be an internal-toothed friction disc.
25. On the conventional output shaft transmissions: T313–T318(L)(LR), install the shaft snap ring into the second groove from the front end of the rear mainshaft. 382
24. Install the synchronizer disc pack spacer onto the synchronizer friction disc just installed. Lubricate the spacer with the specified gear oil during installation 381
Figure 382 — Installing Shaft Snap Ring (T313L/T318L Shown)
26. For the conventional output shaft transmissions: T313–T318(L)(LR), install the larger gear snap ring into the second from rear groove of the Hi-range/Hi-split gear.
Figure 381 — Installing Spacer (T313L/T318L Shown)
There are four grooves on the inside of the Hi-range/Hi-split gear. The two outer grooves are relief grooves and are not to be used to retain snap rings. To properly retain the current design ball bearing, use only the two inner snap ring grooves.
Page 155
