REPAIR INSTRUCTIONS 3. Remove the spacer located between the Lo-split gear and the Hi-range/Hi-split gear.
295
4. Press the Hi-range/Hi-split gear from the countershaft. Note that the hub of the gear faces forward. 293
Figure 295 — Exploded View of Rear Countershaft Bearing Cover 1. Bearing Cup 2. O-Ring Figure 293 — Pressing off Hi-Range/Hi-Split Gear
5. Remove the key from the keyway of the rear countershaft.
Rear Countershaft Bearing Cover Disassembly
3. Shim(s) 4. Bearing Cover
The following procedure applies to all three rear countershaft bearing covers. 1. Remove the shim(s) and O-ring from the shoulder of the countershaft rear bearing cover. Tag the shim(s) and record the markings for use during assembly. 296
[321] 294
Figure 296 — Removing Cover Shims and O-Ring
Figure 294 — Rear Countershaft Bearing Cover Component Locator (T313L/T318L Shown)
Page 124
