REPAIR INSTRUCTIONS Front Countershaft Front Bearing Cover Disassembly
The following procedure applies to all three front countershaft front bearing covers.
[321]
1. Remove the O-ring from the shoulder of the front countershaft front bearing cover. 275
273
Figure 273 — Front Countershaft Front Bearing Cover Component Locator (T313L/T318L Shown) 274
Figure 275 — Removing O-Ring from Shoulder of Front Countershaft Front Bearing Cover
2. Remove the bearing cone from the front countershaft front bearing cover, using a suitable puller such as J 39477 with bearing separator J 8176 or equivalent. 276
Figure 274 — Exploded View of Front Countershaft Front Bearing Cover 1. O-Ring 2. Bearing Cone
3. Front Bearing Cover Figure 276 — Removing Bearing Cone from Front Countershaft Front Bearing Cover
3. Thoroughly clean the bearing cover and inspect for damage.
Page 118
