REPAIR INSTRUCTIONS 22. Continue removing the friction and reaction discs until all are removed.
25. Remove the larger snap ring that secures the Lo-range gear to the gear hub. 254
23. Remove the shaft snap ring from inside the Lo-range gear hub. 252
Figure 252 — Removing Shaft Snap Ring
24. Remove the internal-toothed thrust washer from inside the Lo-range gear hub. 253
Figure 254 — Removing Gear-to-Hub Snap Ring (T313L/T318L Shown)
26. Remove the Lo-range gear from the hub. Notice that the ground surface on the gear faces the front of the transmission. 255
Figure 253 — Removing Hub Thrust Washer (T313L/T318L Shown)
Page 112
Figure 255 — Removing Lo-Range Gear from Hub (T313L/T318L Shown)
