REPAIR INSTRUCTIONS 6. On the conventional output shaft transmissions: T313–T318(L)(LR), remove the remaining rear snap ring from inside the Hi-range/Hi-split gear. 237
8. For the extended output shaft transmissions: T313–T318(21)(L21)(LR21), remove the snap ring from the front end of the output shaft, using suitable snap ring pliers. 239
Figure 237 — Removing Remaining Gear Snap Ring (T313L/T318L Shown)
Figure 239 — Removing Snap Ring from Front of Shaft (T313L21/T318L21 Shown)
1. Rear Snap Ring Groove
9. On the extended output shaft transmissions: T313–T318(21)(L21)(LR21), remove the internal-toothed and external-toothed thrust washers from the front end of the output shaft. Note that the oil grooves of the external-toothed thrust washer face the front of the shaft toward the internal-toothed thrust washer.
2. Gear Machining Relief Grooves
7. For the conventional output shaft transmissions: T313–T318(L)(LR), remove the remaining snap ring from the front end of the rear mainshaft. 238
240
Figure 238 — Removing Shaft Snap Ring (T313L/T318L Shown)
Page 108
Figure 240 — Removing Thrust Washers (T313L21/T318L21 Shown)
