Control, operation
Operating instructions
Working with the machine
Note! If the machine is generally being used for hammer operation, there is a risk that the hydraulic oil becomes contaminated quicker than usual. Adjust the maintenance intervals for hydraulic oil and filter cartridge changes for heavy dust application.
3.4.10.1
Accessory kit AHS 1 Accessory kit AHS 1 can be used to operate the adjustable boom cylinders for a hydraulically adjustable boom or for a side adjustable gooseneck boom.
Fig. 3-61
Accessory kit AHS 1
To operate the adjustable boom cylinder: Push the foot pedal k down. The adjustable boom cylinder will be extended, i.e. the attachment moves up. Push down foot pedal m. The adjustable boom cylinder will be retracted, i.e. the attachment moves down.
3.4.10.2
Accessory kit AHS 11 With accessory kit AHS 11, only one additional user can be operated, i. e. one working tool (such as the hydraulic hammer) can be operated with the gooseneck boom.
Fig. 3-62
Accessory kit AHS 11
A suitable operating mode can be selected using switch S241. The switch has three positions:
3 - 58
MJFCIFSS
A 316 Litronic / 8720369
