Control, operation
Operating instructions
Working with the machine
3.4.8
Lowering the attachment when the engine is not running In an emergency, the attachment can be lowered, even if the engine is not running.
Fig. 3-58
Lowering the attachment when engine is not running
Turn the ignition key to contact position 1. Operate the joystick or the foot pedals until the attachment is lowered. Note The attachment can be lowered because of This reserve is limited and is only sufficient for small movements of the pilot control devices. Move the joystick only in the direction for lowering the attachment.
3.4.9
Turning, rotating, locking and unlocking the attachments Switch S19 is used to activate an additional function:
Fig. 3-59
Attachment examples
To operate, press the push button. The push buttons are located on the left and /or right joystick (depending on the machine configuration):
3 - 56
MJFCIFSS
A 316 Litronic / 8720369
