Control, operation
Operating instructions
Working with the machine
Caution! The sensor controlled low idle automatic must be turned off when starting up the Diesel engine. The indicator light in the switch may not light up.
3.4.3
Operating the swing gear Caution! The machine is delivered in series with PCSA controls. On request, the machine can be equipped with a control system that deviates from the PCSA controls (e.g. LIEBHERR control). In this case, observe the additional operating instructions for this control. The joystick functions described here refer exclusively to PCSA controls.
3.4.3.1
Turning the uppercarriage The uppercarriage is turned with the left joystick.
Fig. 3-47
Turning the uppercarriage
Deflect the joystick to the left c. The uppercarriage turns to the left. Deflect the joystick to the right d. The uppercarriage turns to the right.
3.4.3.2
Slowing the uppercarriage down The machine is equipped with a hydraulic and a mechanical swing gear brake.
Hydraulic swing gear brake Move the left joystick 4 to neutral. The uppercarriage will be adequately slowed down hydraulically. Move the left joystick 4 in the opposite direction. The uppercarriage will be hydraulically slowed down to the maximum degree.
3 - 50
MJFCIFSS
A 316 Litronic / 8720369
