Control, operation
Operating instructions
Operation
Slowly press travel pedal 7 down.
Travelling reverse Press rocker switch S263 up b. The indicator light H168 lights up. Slowly press travel pedal 7 down.
3.3.4.6
Travelling downhill The machine is equipped with an automatic brake valve, which prevents the hydraulic drive train from overspeeding. Danger! Before travelling downhill, turn the sensor controlled low idle automatic S20 off.
Travel downhill with maximum Diesel engine RPM. Regulate the speed using the travelling pedal.
3.3.4.7
Travelling on downhill grades of more than 10% Caution! Applying the operating brake does not ensure safe parking on a downhill slope (loss of pressure due to leakage is possible). Before leaving the cab and / or shutting down the machine, apply the parking brake S16. Raise the safety lever. Always use the 1st gear to travel downhill slopes of more than 10%. Before travelling downhill, stop and engage the 1st gear.
3.3.5
Travelling on public roads Note! Travelling on public roads is subject to national regulations. Before starting to travel, inform yourself about local requirements. Observe all regulations and conditions.
Fig. 3-36
3 - 38
Required additional equipment, Germany
MJFCIFSS
A 316 Litronic / 8720369
