Control, operation
Operating instructions
Operation
Turning the electrical system on
Fig. 3-31
Battery master switch
The battery master switch must be in position 1 (ON). Turn the ignition key to contact position 1. As soon as the ignition is turned on, the keypads and the display instruments runs through a self check. Note! If the keypad and display instruments do not run through a self check when the ignition key is in contact position, check if the battery master switch is positioned on
Make sure that the display instruments are functioning perfectly when they are turned on. All indicator lights must turn on briefly.
Electronic immobilizer (option) On request, the machine can be equipped with an electronic immobilizer.
Fig. 3-32
Electronic immobilizer
Insert the coding key 1 in the coding lock S74 and then remove it again. The LED turns off. A signal tone sounds. Turn the electrical system on. Use the ignition key to start the electrical system within 9 seconds. If the ignition is not turned on within 9 seconds, the coding key must be reinserted in the coding lock.
3 - 32
MJFCIFSS
A 316 Litronic / 8720369
