Control, operation
Operating instructions
Operating and control elements
S61 - Headlight This switch has three settings: Neutral (0), Position 1 and 2. Push the switch in position 1 down (center position). The parking light is activated. Push the switch in position 2 down (final position). The headlight is activated. The switch is also functioning if the ignition key is in position 0 or P.
Press switch. The corresponding outrigger is activated. The indicator light in the switch lights up. Press switch again. The corresponding outrigger is deactivated. The indicator light in the switch turns off. S218 - Windshield wiper on cab roof (green) This switch has three settings: Neutral (0), Position 1 and 2. Push the switch in position 1 down (center position). Continuous operation is activated. Push the switch down to position 2 and hold (final position). Water will be sprayed on the windshield. The windshield wiper runs continuously. S241 - Auxiliary user (green)* This switch has three settings: Neutral (0), Position 1 and 2. Push the switch in position 1 down (center position). The auxiliary user with high pressure (e.g. sorting grapple, scrap cutter) is activated. The indicator light H196 lights up. Push the switch in position 2 down (final position). The auxiliary user with reduced pressure (e.g. hydraulic hammer, ram) is activated. The indicator light H196 turns off. The indicator light in the switch lights up. S318 - Air conditioning system (green)* Press switch down. The air conditioning system is turned on. The indicator light in the switch lights up. Press switch up. The air conditioning system is turned off. The indicator light in the switch turns off. S335 - Blade support (green) Press switch. The dozer blade is activated. The indicator light in the switch lights up.
3 - 12
MJFCIFSS
A 316 Litronic / 8720369
