Control, operation
Operating instructions
Operating and control elements
H13 - Indicator light - Air filter contamination (orange) The indicator light lights up if the air filter is very dirty. Bring the Diesel engine to low idle immediately. Continue to let the engine run in low idle for approx. 5 seconds. Shut down the Diesel engine. If necessary, replace the filter element. H15 - Indicator light - Hydraulic oil temperature (red) The indicator light lights up if the hydraulic oil temperature in the tank exceeds 98 °C. Bring the Diesel engine to low idle immediately. Shut down the Diesel engine as quickly as possible. Find and remedy the error (radiator dirty, etc.). H16 - Indicator light - Overload warning (red)* The indicator light lights up if the maximum permissible load carrying capacity of the machine is reached and the overload warning device S18 is turned on. The buzzer in the cab sounds simultaneously. Avoid increasing the load any further. Reduce the load on the machine. H18 - Indicator light - Coolant level low (red) The indicator light lights up if the coolant level drops below a specified level. Bring the Diesel engine to low idle immediately. Shut down the Diesel engine as quickly as possible. Find and fix the leak. Caution! This monitoring device increases the level of security in case of loss of larger amounts of water (e.g. hose rupture). It does not relieve the operator or maintenance personnel from the responsibility of regularly checking the coolant level in the expansion tank. H19 - Indicator light, turn signal The indicator light lights up if the turn signal switch and the hazard warning system are actuated. H20 - Indicator light, parking brake The indicator light lights up if the parking brake is applied (S16) or if the parking brake's release pressure is too low. H23 - Indicator light, accumulator charge pressure - operating brake (red)* The indicator light lights up if the accumulator charge pressure is too low. The brake function is endangered. Bring the machine to a standstill. Bring the Diesel engine to low idle immediately. Fold the safety lever up. Check the brake system.
3-8
MJFCIFSS
A 316 Litronic / 8720369
